9.2.5 SIDE AIR VENTS

REMOVAL

1. Carefully Pry out the side air vent from RHS

2. Follow the same procedure on the other side.

FITMENT

For fitment follow the reverse procedure of

removal.

9.2.6 FRONT BUMPER

REMOVAL

1. Open the bonnet.

2. Loosen and remove the four mounting screws

along with the washers from the top side of the

bumper.

3. Remove two clip buttons from the bumper

which hold the head lamps.

4. Loosen the five mounting screws at the bottom

of the bumper.
