5. Loosen and remove two mounting screws of
the outer liner from the inner side of wheel
arch. Follow the same procedure at the other
end also.
6. Pry out the front bumper from wheel arch end.
7. Disconnect fog lamp connectors and remove
the bumper.
FITMENT
For fitment follow the reverse procedure of
removal.
9.2.7 REAR BUMPER
REMOVAL
1. Open the tail gate.
2. Loosen and remove four rear bumper special
screw on top side.
3. Loosen and remove all rear bumper screws
and bolts which hold the rear bumper from
bottom side.
