5. Slide the Housing in horizontal / X direction
towards vehicle front and remove the lever
with Housing assembly from Door Inner panel.
6. Disconnect the cable from inner lock handle
connecting inner handle to latch assembly
power front.
7. Remove door inner lock handle.
FITMENT
For fitment follow the reverse procedure of
removal.
9.2.11 FRONT OUTER DOOR LOCK
REMOVAL
1. Remove the door trim. (For procedure refer
front door trim removal process.)
2. Remove the plug.
3. Remove the mounting screw of front door lock.
4. Remove the lock barrel.
