BODY
19
9.2.4 GLOVE BOX
REMOVAL
1. Open the glove box and pry out AC adaptor
top Utility Bin.
2. Remove glow box damper pin.
3. Rotate glow box assembly with 50
in
downward direction and pull out from hinges.
4. Remove the glow box assembly along with
damper from the dashboard.
FITMENT
For fitment press the glove box assembly against
the dashboard.
