TIAGO

ELECTRICAL

168

4.2 ACCESSORY DELAY FUNCTIONALITY.

4.2.1 Description

The 'Accessory Delay Power Mode 'allows the user to close the windows after ignition OFF. This feature

may also allow other functions like sunroof close.

4.2.2 Conditional Requirements



Once the key is taken out (IGN ON



ACC



Key IN



Key OUT) and if the user forgets to close the any

window then BCM allows the user to close the windows without turning the IGN ON for predefined time (3

minutes) before opening the driver door or before locking the vehicle successfully with RKE.



On Fault –

BCM logs respective DTC.

4.2.3 Operating Voltage Range

DESCRIPTION

REQUIREMENT

VOLTAGE

Accessory

Delay

Functionality.

Normal operating voltage

12V

Normal operating voltage range For Hazard:

6.5V - 16V.

Normal operating voltage range for CAN & LIN communication 7V - 16V

Normal operating voltage range for other

9V-16V

4.2.4 Inputs & Outputs
