TIAGO

750 / 1002

ELECTRICAL
129
MAINTENANCE AND TROUBLE SHOOTING
CONDITION POSSIBLE CAUSE CORRECTION/REFERENCE ITEM
ECU Communication Error 1) OBD connection
 Check the OBD cable connection with
Diagnostic Connector of vehicle.
 Check the OBD cable connection with
Silicon Engine module
2) Com port connection
 Check the com settings.
 Connect RS232 cable to COM Port.
 Check the ‘DSR’ and ‘DTR’ LEDs are on
Rs232 Silicon Engine module. If both are Red
re-initialize the unit.
3) PCMCIA Card Connection
 For details read the reference document
“PCMCIA_Card_Port_SettingsPDF” available
on site
4) USB Port Connection
 Check the USB LED on USB Silicon
Engine.
 If it is red then connect USB Cable to USB
Port and Install the drivers from the CD or
from the application path directory.
 Check the USB LED on USB Silicon
Engine.
If it is green then initialize the unit.
Software Not Working Corrupt version of Software  Reinstall the software.
