ELECTRICAL
111
FOR 20 PIN CONNECTOR
SR.
NO
DESCRIPTION
TYPE
OF
INPUT
INPUT
/OUTPUT
ACTIVE
LEVEL/
STATE
DIAGO-
NASTIC
IC-Low
end
IC-High
End
1
NC
2
NC
3
NC
4
NC
5
NC
6
NC
7
NC
8
Driver Door Open IN
Digital Input
Low
NA
Y
NA
9
Turn Right IN
Digital Input
High
NA
Y
NA
10 Key IN
Digital Input
High
NA
Y
NA
11 NC
12 NC
13 NC
14 NC
15 NC
16 NC
17 Park Bulb IN
Digital Input
High
NA
Y
NA
18 All Other Door Open IN
Digital Input
Low
NA
Y
NA
19 NC
20 Turn Left IN
Digital Input
High
NA
Y
NA
NA-Not applicable, PP- Package protected, Y- applicable.
8.23.6 FUEL GAUGE DETAILS:
Fuel level indication:
FUEL VS RESISTANCE TABLE
FOR INSTRUMENT CLUSTER HIGH END
SEGMENT
TANK
LEVEL(Lit)
RESISTANCE
(OHMS)
BAR ON
RESISTANCE
(OHMS)
BAR OFF
RESISTANCE
(OHMS)
LOW FUEL
WARING TT
TOLERANCE(±2 OHMS)
SHORT CIRCUIT
5
BLINK @ 2Hz
44.0
6
6
42.0
10
12
22
OFF
5
35.7
24
26
38
OFF
4
29.3
40
42
54
OFF
3
23.0
56
58
74
OFF
2
15.5
76
78
95
OFF
1
8.0
97
99
109
ON ( 2
nd
bar
OFF)
1 BAR BLINK
4.0
111
IGN ON
ON
1.5
120
134
OPEN CIRCUIT
135
BLINK @ 2Hz
