FUEL VS RESISTANCE TABLE
FOR INSTRUMENT CLUSTER LOW END
SEGMENT
TANK
LEVEL(Lit)
RESISTANCE
(OHMS)
BAR ON
RESISTANCE
(OHMS)
BAR OFF
RESISTANCE
(OHMS)
LOW FUEL
WARING TT
TOLERANCE(±2 OHMS)
SHORT CIRCUIT
5
BLINK @ 2Hz
35
6
10
34.0
8
10
16
OFF
9
31.7
18
20
26
OFF
8
29.4
28
30
36
OFF
7
27.0
38
40
46
OFF
6
23.2
48
50
56
OFF
5
19.2
58
60
66
OFF
4
16.6
68
70
76
OFF
3
14.0
78
80
86
OFF
2
11.4
88
90
97
OFF
1
6.25
99
101
117
ON ( 2
nd
bar
OFF)
1 BAR BLINK
3.1
119
IGN ON
ON
1.0
127
134
OPEN CIRCUIT
135
BLINK @ 2Hz
8.23.7 TEMPERATURE BAR GRAPH DETAILS
:
Temperature indication:
TEMPERATURE CALIBRATION TABLE
SEGMENT
BAR ON TEMP. (ºC)
BAR OFF TEMP. (ºC)
6seg
120
115
5seg
115
110
4seg
110
105
3seg
90
85
2seg
85
80
1seg (C)
-40
NA
Input type:
Can
Output:
LED bar graph in Instrument Cluster high end.
Absent in Instrument Cluster low end.
ECT TT (Duel Colour)
