TIAGO

ELECTRICAL

106

8.23.4 DTC FOR INSTRUMENT CLUSTER

B190B-11

Ambient Temperature Sensor Input Short To Ground

B190B-15

Ambient Temperature Sensor Input Short To Battery or Open

B1909-11

Fuel Level Sensor Input Short To Ground

B1909-15

Fuel Level Sensor Input Short To Battery or Open

B1938-06

Vehicle Speed Sensor Algorithm Based Failure

B1939-86

Vehicle Speed Signal output Implausible Signal Invalid

B191C-11

Vehicle Speed Sensor Power Supply Output Short To Ground

U1010-14

Key In Signal Input Short To Ground or Open

B1934-09

Set Switch Stuck Button Component Failures

B1935-09

Mode Switch Stuck Button Component Failures

B1936-56

Odometer Values missing From VICM (Immobilizer) for Learning

B1937-31

Acknowledgement missing from VICM for Learning

U100F-06

Ignition Power mode Input Algorithm Based Failures

B191E-11

Illumination Dimming Level Output Short to Ground

B191E-12

Illumination Dimming Level Output Short to Battery

U3006-16

Control Module Input Power “A” – Circuit Voltage below Threshold

U3006-17

Control Module Input Power “A” – Circuit Voltage above Threshold

U3000-08

Control Module Bus Signal / Message Failures

U1604 – 55

Control Module Configuration not configured

B1912-15

Park Brake Warning Indicator Input circuit short to battery or open

B1912-11

Park Brake Warning Indicator Input circuit short to ground

B1911-15

Brake Fluid Level Warning Indicator Input circuit short to battery or open

B1911-11

Brake Fluid Level Warning Indicator Input circuit short to ground

B190F-15

Driver Seat Belt Warning Indicator Input circuit short to battery or open

B190F-11

Driver Seat Belt Warning Indicator Input circuit short to ground

B1917-15

Driver Door Ajar Warning Indicator Input circuit short to battery or open

B1917-11

Driver Door Ajar Warning Indicator Input circuit short to ground

B191A-14

Park Lamp Input (Position Lamp Input) circuit short to ground or open

B191A-12

Park Lamp Input (Position Lamp Input) circuit short to battery

B1914-12

Turn Left Indicator Input circuit short to Battery

B1914-14

Turn Left Indicator Input circuit short to Ground or Open

B1915-12

Turn Right Indicator Input circuit short to Battery

B1915-14

Turn Right Indicator Input circuit short to Ground or open

U1018-14

Transport Mode Selector Input circuit short to ground or open

U1018-12

Transport Mode Selector Input circuit short to battery
