4.7. U. REMOVAL OF GEAR SHIFTER
HOUSING, GEAR SHIFTER AND
SELECTOR CABLE:
1. Ensure the gear lever in neutral condition.
2. Remove Lever knob, washer, cap screw and
base plate. (Refer body section).
3. Remove the central floor console. (Refer body
section).
4. Pry out both the cable lock plates and remove
the cables from assembly gear shift housing.
5. Loosen/remove selector cable fastener to
remove selector cable.
6. Unscrew the four bolts of gear shifter lever
housing to remove it.
7. Rotate gear shifter housing, Remove lock pin
& pry out the shifter cable.
8. Pry out the shifter selector cable ends from
the transaxle housing.
9. Pull out the plunger from transaxle cable
and remove it from the transaxle cable
anchoring bracket.
