TIAGO

DRIVETRAIN-TA65 Star

36. Try out the oil seal from the cover (if

damaged) and

replace it with new one.

37. Remove the plastic bushes at both ends of

clutch release fork and remove the clutch

release shaft from inside.

38. Remove oil seals of drive shaft from

differential housing.

Replace it with a new

one while assembling.

39. Remove bearing outer races of differential

side bearing along with shims. Ensure that

outer races are not interchanged.

NOTE: SHIMS SHOULD NOT BE REUSED.

NOTE:

1. Apply anabond 112 on threads of all fasteners

2. Apply RTV silicon liquid gasket anabond 676

on housing interface.

3. The chips collected by magnetic drain plug,

are to be removed at the time of every oil

change.

4. Keep inner and outer races of taper roller

bearing in sets.

5. Use sealing anaerobic compound for all oil

seals outer diameter.

6. For oil seals of input drive shaft and bellows

use anabond 112.
