1.05L REVOTORQ ENGINE
34
I. INTAKE SYSTEM :
INTAKE SYSTEM :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Gasket (Elbow for EGR Valve to Cylinder
Head)
02
Elbow (For EGR Valve)
03
EGR Elbow on Cylinder Head
(Nut AM6) (Qty - 2)
1+0.2
04
EGR Valve on Elbow
(Hex Fl Nut AM6) (Qty - 2)
1+0.2
05
Intake Manifold
06
Gasket (For Charge Air Pipe)
