1.05L REVOTORQ ENGINE
35
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
07
Charge Air Pipe to Intake Manifold
(Hex Fl Nut AM6) (Qty - 3)
1+0.2
08
Charge Air Pipe
09
Assembly EGR Valve
10
Gasket (EGR Intake Pipe to EGR Valve)
11
EGR Pipe Assembly
12
EGR Pipe (Both Ends) Assembly
(Hex Fl Bolt M8X20) (Qty - 4)
1+0.2
13
Gasket (EGR Intake Pipe to EGR Valve)
14
Hex FL Screw M6X16 (Qty - 2)
1+0.2
15
Assembly Vacuum Modulator
16
Oil Mist Separator Assembly
17
Oil Separator Bracket on Intake Manifold
(Hex Fl Screw M6X14)
1+0.2
18
Oil Separator on Oil Separator Bracket
(Hex Fl Nut AM6)
1+0.2
19
Intake Manifold on Cylinder Head
(Cap Screw M8X35) (Qty - 4)
•
2+0.3
20
Intake Manifold on Cylinder Head
(Clinch Nut CM8X1.25) (Qty - 3)
•
2+0.3
21
Intake Manifold
22
Bracket (For Air Filter Mounting)
23
Bracket (For Air Filter Mounting) on Intake
Manifold (Hex Fl Screw M6X10) (Qty - 2)
1+0.2
24
Gasket (Intake Manifold)
Note :
•
This Symbol indicates critical tightening torque.
