TIAGO

244 / 1002

1.05L REVOTORQ ENGINE
33
ITEM
NO. DESCRIPTION
NO REUSE SEALANT
LUBRICATIONTIGHTENING
TORQUE(kg-m)
06 Heat Shield Exhaust Manifold Top
07 Gasket (Exhaust Manifold)
08 Exhaust Manifold
09 Turbocharger on Exhaust manifold (Hex fl
Bolt M8X55) (Qty - 3) 2+0.3
10 Heat Shield Exhaust Manifold Bottom
11 Bottom Heat Shield on Exhaust Manifold
(Hex Fl Screw M6X10) 1+0.2
12
Exhaust Manifold on Cylinder Head (Clinch
Nut M8X1.25) (Qty - 8) • 2+0.3
13 Gasket (Turbocharger Inlet to Exhaust
Manifold)
14 Closed Coupled Catalytic Converter
Assembly
15 CCC on Exhaust Elbow (Clinch Nut
CM8X1.25) (Qty - 3) 2+0.3
16 Gasket (Exhaust Elbow and CCC)
17 CCC on Exhaust Elbow (Stud BM8X20) 2+0.3
18 Exhaust Elbow on Turbocharger
(Clinch Nut CM8X1.25) (Qty - 3) 2+0.3
19
Heat Shield Assembly (Exhaust Elbow)
(Hex Fl Screw M6X20) (Qty - 2) 1+0.2
20 Heat Shield Assembly (Exhaust Elbow)
21 Gasket (Turbocharger Outlet to Exhaust
Elbow)
Note :
• This Symbol indicates critical tightening torque.
