248 / 1002
1.05L REVOTORQ ENGINE
37
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
07
Hex Screw M10X1.25 (Qty - 2)
6.5
08
Stud of Dia for 'B' Mount
09
Hex Fl Bolt M10X40 (Qty - 3)
4.2
10
'B' Mount - Transaxle Side
11
Assembly C Mount Link
12
Hex Fl Bolt M10x80 (Qty - 1)
5.4
13
Hex Fl Bolt M10x75 (Qty - 1)
5.4
14
C-Mount-Bracket
15
Hex Fl Screw M10X18 (Qty - 2)
4
16
Bright Washer
17
Nyloc Nut M10
18
Assembly 'C' mount
19
Hex Fl Screw M10X25 (Qty - 3)
5.4
20
Hex Fl Screw M10X1.25X30 (Qty - 2)
5.8
21
'A' Mount Bracket
22
Hex Fl Screw M10X1.25X30 (Qty - 2)
5.8
23
Hex Fl Screw M10X1.25X30 (Qty - 2)
5.8
24
'A' mount
25
Bright Washer
26
'A' Mount Arm
27
Nyloc Nut M10
6.3
28
Hex Fl Nut AM10 (Qty - 3)
6.3
