1.05L REVOTORQ ENGINE
38
K. MOVING PARTS :
MOVING PARTS :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Gudgeon Pin
02
Bush Connecting Rod
03
Bearing Half Lower Connecting Rod
04
Gear (On Crankshaft)
05
Vibration Damper Assembly
06
Crankshaft Gear to Crankshaft
(Hex. Bolt M16X61)
4+60
0
