1.05L REVOTORQ ENGINE
31
SPECIAL INSTALLATION :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Bracket (For Alternator Mounting)
02
Alternator Bracket to Crankcase
(Hex Fl Bolt M8X35) (Qty - 4)
2+0.3
03
Alternator Bracket to Alternator
(Hex Fl Bolt M8X55)
2+0.3
04
Assembly Autotensioner
05
Autotensioner on Alternator Bracket
(Hex Fl Screw M10X35) (Qty - 1)
4.5+0.5
06
Autotensioner on A/C Bracket
(Hex Fl Screw M8X40) (Qty - 1)
2.5+0.3
07
Belt Poly
08
Hex Fl Bolt M8X125 (For Alternator
Mounting)
09
Alternator
10
Bright Washer
11
Alternator to Bracket Hex Bolt with Nyloc
Nut M8
2+0.3
12
AC Compressor on AC Compressor
Bracket (Hex Fl Bolt M8X80) (Qty - 3)
2.5+0.3
13
AC Compressor
14
AC Compressor Bracket to Cylinder Block
(Hex Fl Bolt M8X25) (Qty - 4)
2.5+0.3
15
AC Compressor Mounting Bracket
16
Sealing Plug for Oil Gallery, Block Rear
(M14X1.5)
3.5+0.5
17
Crank Position Sensor
18
Crank Position Sensor to Cylinder Block
(Hex Fl Screw M6X16)
1+0.2
19
Cam Sensor
20
Cam Sensor on Integral Bearing Frame
(Hex Fl Screw M6X16)
0.4+0.2
