240 / 1002
1.05L REVOTORQ ENGINE
29
CYLINDER HEAD :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Assembly Hydraulic Lash Adjuster
02
Valve Lock Half
03
Valve Spring Retainer
04
Valve Spring
05
Spring Seat
06
Valve Stem Seal
07
Screw Plug Gallery Cylinder Head M12X1.5
2+0.3
08
Valve Seat Insert (Intake)
09
Valve Seat Insert (Exhaust)
10
Exhaust Valve
11
Intake Valve
12
Screw Plug Gallery Cylinder Head M14X1.5
2+0.3
13
Camshaft (Exhaust)
14
Cam Gear (Exhaust)
15
Cam Gear (Intake)
16
Camshaft (Intake)
