1.05L REVOTORQ ENGINE
27
OIL SUMP :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Ladder Frame
02
Balancer Shaft Bearing Cap
03
Balancer Shaft Bearing Cap
(Hex Fl Bolt M6X35) (Qty - 6)
•
2+0.3
04
Ladder Frame Assembly on Crankcase
(Cap Screw M6X20) (Qty - 8)
1+0.2
05
Oil Sump
06
Sealing Washer (Oil Sump Drain Plug)
07
Oil Sump on Ladder Frame
(Hex Fl Bolt M6X30) (Qty - 10)
1+0.2
08
Oil Sump on Ladder Frame
(Hex Fl Screw M6X10) (Qty - 11)
1+0.2
09
Oil Sump Drain Plug (M16X1.5)
3.5+0.5
10
Stiffener (Hex Fl Bolt M8X40) (Qty - 2)
2.5+0.3
11
Stiffener
12
Gasket (Rear Cover Crankcase)
13
Rear Cover Crankcase
14
Assembly Rear Cover on Cylinder
Crankcase (Hex Fl Screw M6X20) (Qty - 6)
1+0.2
15
Crankshaft oil Seal (Rear)
Note :
•
This Symbol indicates critical tightening torque.
