1.05L REVOTORQ ENGINE

25

ENGINE :

ITEM

NO.

DESCRIPTION

NO REUSE

SEALANT

LUBRICATION

TIGHTENING

TORQUE

(kg-m)

01

Assembly Water Inlet Elbow

02

Water Inlet Elbow on Crankcase

(Hex Fl Screw M8X20) (Qty - 2)

2.5+0.3

03

Gasket (Assembly Water Inlet Elbow to

Block)

04

Assembly Timing Cover (Back)

05

Timing Cover Back on Block and Head

(Hex Fl Screw M6X16) (Qty - 4)

0.8+0.2

06

Assembly Timing Cover (Front)

07

Timing Cover Front on Head and Integral

Bearing Frame

(Hex Fl Screw M6X16) (Qty - 2)

0.8+0.2

08

Timing Cover Front on Back Cover

(Hex Fl Screw M6X30) (Qty - 2)

0.8+0.2

09

Timing Cover Front on Back Cover

(Hex Fl Screw M6X45) (Qty - 2)

0.8+0.2

10

Bottom Cover on Oil Pump

(Hex Fl Screw M6X16) (Qty - 2)

0.8+0.2

11

Front Cover Bottom

12

Main Bearing Cap

13

Main Bearing Cap

(Bolt M12X1.75) (Qty - 8)

5+90

0

14

CCC Support Bracket

15

CCC On Crankcase

(Hex Fl Screw M6X14) (Qty - 2)

1+0.2

Note :

This Symbol indicates critical tightening torque.
