1.2L REVOTRON ENGINE

98



PRE-SILENCER REMOVAL

1. Loosen and remove the Pre-silencer mounting

bolts

(3 Nos.).

2. Remove the one rubber hanger from front end

of pre silencer and other one is from rear end.

3. Take out the Pre silencer assembly.

FITMENT

For fitment follow reverse procedure of removal.



FRONT PIPE WITH CLOSED CATALYTIC

CONVERTER

REMOVAL

1. Remove all connections including lambda

sensor.

2. Remove the clamps by loosening the bolts.

3. Remove Front pipe.

4. Remove the heat shield of CCC.

5. Loosen and remove the intake manifold nuts.
