104 / 1002
1.2L REVOTRON ENGINE
67
Maintenance Limit (REVOTRON 1.2L)
Small end parent bore cylindricity
0.008 mm
Connecting rod small end bush inside diameter (finished after installation)
18.007/18.020 mm
Maximum permissible out of parallelism (bend) between connecting rod small
end and big end parent bores.
0.015 mm
Center to center distance between connecting rod small end and big end
parent bores
138.8
± 0.03
mm
Maximum permissible twist of connecting rod
0.030 mm
Connecting rod big end parent bore diameter
45.000/45.016 mm
Big end parent bore and cylindricity
0.01 mm
Bearing shell to be selected such that clearance is maintained as
0.027 - 0.066 mm
Crush height of connecting rod big end bearing shells
0.025 - 0.055 mm
Connecting rod big end axial play
0.05 - 0.35 mm
