1.2L REVOTRON ENGINE
64
Camshaft Dimensions (REVOTRON 1.2L)
Maximum permissible runout of camshaft bearing journal
0.020 mm
Maximum permissible axial play of camshaft (installed)
0.1-0.3 mm
Journal Dimensions
From Front of engine
Camshaft Bearing Bore I.D.
Camshaft Bearing Journal O.D.
Intake
1
30.040 - 30.061 mm
29.979 – 30.000 mm
2
22.040 - 22.061 mm
21.979 – 20.000 mm
3
22.040 - 22.061 mm
21.979 – 20.000 mm
4
22.040 - 22.061 mm
21.979 – 20.000 mm
Exhaust
1
24.040 - 24.061 mm
23.979 – 24.000 mm
2
22.040 - 22.061 mm
21.979 – 22.000 mm
3
22.040 - 22.061 mm
21.979 – 22.000 mm
4
22.040 - 22.061 mm
21.979 – 22.000 mm
