2. The specified resistance values and calibration details of the Suction unit fuel gauge are given below :
44 liters tank
Parameters
Float positions
FULL
3//4
HALF
1//4
EMPTY HIGHT
EMPTY
LOW
Resistance value in OHMS
8
34
58
89
100
120
Tolarance in OHMS
±2
±2
±2
±2
±2
±2
Height in MM
176
140
104
60
45
+0 -2
21
Volume (LTRS) (USABLE)
(42±1)
(32±1) (22±1) (10.7±1)
(7±1)
(1.5±1)
