ENGINE 1.3L QUADRAJET (90PS)
89
I. ASSEMBLY FILLER NECK COMPLETE:
The fuel tank filler neck is a long tube that goes down
to the center of the gas tank. It is also equipped with
breath line.
REMOVAL:
1) Relieve the fuel system pressure and disconnect
the negative battery cable.
2) Remove the fuel filler cap from the fuel tank.
3) Use a hand operated pump device to drain asmuch
fuel through the fuel filler neck as possible.
4) Reinstall the fuel filler cap.
5) Remove the rear seat cushion from vehicle (if so
equipped).
6) Disconnect the Mating Electrical connector on tank
unit under rear seat carpet.
7) Raise and safely support the vehicle.
8) Remove the fuel filler hose clamp from the filler
neck assembly.
9) Remove the fuel breather hose clamp from the filler
neck assembly.
10)A small amount of fuel may be released during re-
pair work. To avoid the chance of injury, cover the
pipe to be disconnected with cotton cloth. Do not
use cotton waste.
11) Loosen the filler pipe mounting bolts.
12)Take out the filler pipe.
INSTALL:
1) Reconnect all fuel hoses, lines and the fuel breather
hose to the fuel tank.
2) Install the fuel breather hose and hose clamp to
the filler neck assembly.
3) Lower the vehicle. Connect the Mating Electrical
connector on tank unit under rear seat carpet.
4) Install the rear seat cushion. Reconnect the nega-
tive battery cable
