ENGINE 1.3L QUADRAJET (90PS)
77
3. Unscrew fuel tank unit cover screw and remove
cover.
4. Disconnect Tank Unit Electrical Connector From
Tank Unit.
5. Disconnect tank unit inlet and outlet Quick Con-
nect Couplers:
6. Remove tank unit supporting bracket fasteners.
7. Tank Unit Supporting Bracket Removed: Photo
“Supporting Bkt. Removed.
8. Hold Tank Unit And tilt To Remove from tank: Photo
“Tank Unit Removed”.
