Revotron 1.2T
94
7. Unlock the injectors lock screw of each from
the fuel rail.
8. Remove the Injector Retainer.
9. Remove the Injectors.
10. Remove the Intake Manifold Support Bracket.
11. Remove the Electronic Throttle Control and
Gasket.
