1. Park Assist:
Park Assist feature will assists you to park vehicle safely in reverse to avoid objects which can hit or damage
the rear bumper by alerting with audible and visual information from car infotainment system. Audible and
visual information is with respect to the proximity of the object from the rear bumper.
Park Assist is useful while you are parking the vehicle in congested and close parking area.
2. Park Assist functionality overview:
There are 4 ultrasonic sensors placed on the rear bumper of the vehicle. Once Park Assist system gets
activated, sensors will start detecting the proximity of an obstacle approximately0cm to 150cm from the rear
bumper and gives the proximity information to Infotainment music system in the form of audio and visual
information.
Distance range
from Bumper
(in cm)
Visual Information
Audible Information
0-50
Red Zone
Continuous beep
51-100
Yellow Zone
Fast beep
101-150
Green Zone
Slow beep
0-25cm obstacle detection performance is not guaranteed due to ultrasonic sensor technology
limitation.
3. Park Assist Activation Procedure:
There are 3 ways to activate Park Assist:
→Reverse gear:
→Park assist feature will automatically start functioning once you engage the reverse gear.
→Park assist Button:
→When you press the “Park Button” on the Fascia switch, Park assist feature will start functioning.
→Infotainment music system touch display:
→In Infotainment system user interface, press the following button sequence to enable the park assist
feature,
