20. List of Diagnosis Troubleshooting Codes for Reverse Park Assist System (RPAS):
Sr no Display
DTC Code DTC Description
1 B1926-11 PDC Activation Switch Input - Short to Ground
2 B1928-11 PACM Active LED Indicator - Short to Ground
3 B1928-12 PACM Active LED Indicator – Short to Battery
4 B1929-24 Proximity Sensor Rear RH Failure – Signal Stuck High
5 B1929-23 Proximity Sensor Rear RH Failure – Signal Stuck to Low
6 B192A-24 Proximity Sensor Rear Mid RH Failure – Signal Stuck High
7 B192A-23 Proximity Sensor Rear Mid RH Failure – Signal Stuck to Low
8 B192B-24 Proximity Sensor Rear Mid-LH Failure – Signal Stuck High
9 B192B-23 Proximity Sensor Rear Mid LH Failure – Signal Stuck to Low
10 B192C-24 Proximity Sensor Rear LH Failure – Signal Stuck High
11 B192C-23 Proximity Sensor Rear LH Failure – Signal Stuck to Low
12 B1920-11 Proximity Sensor Power Supply Output - Short to GND
13 B1920-12 Proximity Sensor Power Supply Output - Short to Battery
14 U161A-64 HU System Customization Data ACK
15 U0028-13 Vehicle Communication Bus A-open circuit
16 U0028-88 Vehicle Communication Bus A-Bus off
17 U0101-08 Lost communication with TCM- TCM Message Timeout Failure
18 U0140-08 Lost communication with Body Control Module- Message Timeout Failure
19 U130B-08 Lost communication with Head Unit- HU Message Time Out Failure
20 U0155-08 Lost communication with Instrument Panel Cluster Module- Message Time Out
Failure
21 U0402-81 Invalid Data Received From TCM
22 U0423-81 Invalid Data received from Instrument Panel Cluster Module- Invalid serial data
received
23 U0140-87 Lost Communication With Body Control Module (BCM) - Missing message Failure
24 U0155-87 Lost Communication With Instrument Panel Cluster (IPC) Control Module- Missing
message Failure
25 U0101-87 Lost Communication With Transmission control Module (TCU) - Missing message
Failure
