ELECTRICAL
180
SIGNAL OUTPUT @CLUTCH POSITION
PEDAL
POSITION
PEDAL
TRAVEL
OUTPUT
1
<Position 1
<
(65±15%)
O/P-1:V OH
O/P-2:V OH
2
Position 1
(65±15%)
O/P-1:V OL
O/P-2:V OH
3
Position 1-2
>65<75
O/P-1:V OL
O/P-2:V OH
4
Position 2
(75 15%)
O/P-1:V OL
O/P-2:V OL
5
Position 2
(>75
Travel)
O/P-1:V OL
O/P-2:V OL
CLUTCH SENSOR SPECIFICATIONS
1
Principle Of Operation
Hall Effect
Based Position
Sensing
2
Output Type
Open
Collector,
Active Low
3
Sensor Type
Non-Contact
Type (Hall
Effect)
4
No Of Sensing Positions
2
5
Sensing Accuracy At
System Level
15%
6
Sensor Supply
14 V Typical
7
Operating Voltage Range 6V TO 18 V
8
Operating Current
25mA MAX
9
Logic High (Voh)
(Sensor Supply
-1.0V)
10 Logic Low (Vol )
<0.6 V MAX
11 Reverse
Voltage
Supply&
GND
18V MAX,
FOR 1 HOUR
Output&
GND
18V MAX,
FOR 1 HOUR
12 IP Class
IP67
13 Mounting Location
On Clutch
Lever,
Passenger
Compartment
14 Life
10 Lakhs
15 Operating Temp
-30C TO +85C
16 Storage Temp
-40C TO +95C
