ELECTRICAL
176
B1F09 – 11
Interior Lamp Deactivation Signal – Circuit Short to Ground
U1013 – 11
Wake-Up Signal – Circuit Short to Ground
U1013 – 12
Wake-Up Signal – Circuit Short to Battery
U1014 – 09
Ignition Switch Failure
B221E - 11
Heated Rear Windscreen Relay - circuit short to ground
B221E - 15
Heated Rear Windscreen Relay - circuit short to battery or open
B2238- 11
Rear Defogger switch circuit short to GND/ Open
B2238- 12
Rear Defogger switch circuit short to BATT
B2238- 23
Rear Defogger switch circuit short to GND
U1613 – 64
System Customization Data - signal plausibility failure
U1613 – 64
System Customization Data - signal plausibility failure
B220C - 11
Front Washer Switch - Circuit Short to Ground
B220C - 12
Front Washer Switch - Circuit short to Battery or Open Circuit
B220C – 23
Front Washer Switch – Signal Stuck Low
B223B - 11
Rear Washer Switch - Circuit Short to Ground
B223B - 12
Rear Washer Switch - Circuit short to Battery or Open Circuit .
B223B – 23
Rear Washer Switch – Signal Stuck Low
B2212 - 11
Front Wiper Low Speed Switch - Circuit Short to Ground .
B2212 - 12
Front Wiper Low speed Switch - Circuit short to Battery or Open Circuit
B220E - 11
Front Wiper High Speed Switch - Circuit Short to Ground
B220E - 12
Front Wiper High speed Switch - Circuit short to Battery or Open Circuit
B2211 - 11
Front Wiper Intermittent Switch - Circuit Short to Ground
B2211 - 12
Front Wiper Intermittent Switch - Circuit short to Battery or Open Circuit
B223D - 11
Rear Wiper Mode Switch - Circuit Short to Ground
B223D - 12
Rear Wiper Mode Switch - Circuit short to Battery or Open Circuit
B2213 - 11
Front Wiper Park Position Signal - Circuit Short to Ground
B2213 - 12
Front Wiper Park Position Signal - Circuit short to Battery or Open Circuit
B223E - 11
Rear Wiper Park Position Signal - Circuit Short to Ground
B223E - 12
Rear Wiper Park Position Signal - Circuit short to Battery or Open Circuit
B2213 - 92
Front Wiper Park Position Signal - Performance or incorrect operation
B2213 - 97
Front Wiper Park Position Signal - Component or system operation obstructed or
blocked
B223E - 11
Rear Wiper Park Position Signal - Circuit Short to Ground
B223E - 97
Rear Wiper Park Position Signal - Component or system operation obstructed or blocked
B220B- 11
Front Washer Pump Short to Ground
B220B- 15
Front Washer Pump Short to Batt/ Open
B223A- 11
Rear Washer Pump Short to GND
B223A- 15
Rear Washer Pump Short to Batt/ Open
B2258- 14
Wiper On/Off Relay Short to Ground/ Open
B2258- 12
Wiper On/Off Relay Short to BATT
B2256- 14
Wiper High/Low Relay Short to Ground/ Open
B2256- 12
Wiper High/Low Relay Short to BATT
