KRYOTEC ENGINE
103
H. ENGINE OIL FILTER
NOTE
Following a complete replacement of the engine
oil, update the "change engine oil" function in the
specific engine Control Module using the
diagnostic tool.
NOTE
Minimize skin contact with engine oil. Engine oil is
harmful to the skin. In case of contact, wash with
soap and water.
1. Raise and support the vehicle (Refer to 04 -
Vehicle
Quick
Reference/Hoisting/Standard
Procedure)
2. Remove the belly pan (Refer to 13 - Frame and
Bumpers/Under
Body
Protection/BELLY
PAN/Removal and Installation).
3. Remove the cap and insert a suitable drain hose
onto the fitting (1) on the oil filter housing and drain
the oil filter housing.
4. Remove the engine oil filter cover (1).
5. Remove the oil filter element (1) from the oil filter
cover.
6. Remove the O-ring (2) from the oil filter cover.
INSTALLATION
1. Install a NEW oil filter element (1a) engaging the
retaining clips (1b).
2. Install a NEW O-ring (2) on the oil filter cover.
3. Install the oil filter cover and tighten to the proper
(Torque Specifications).
4. Remove the drain hose used for oil recovery and
install the cap on the fitting.
5. Refill the engine lubrication system with the
proper quality and quantity of engine oil (Refer to
04 - Vehicle Quick Reference/Capacities and
Recommended Fluids/Specifications).
NOTE
In the table is shown the amount for periodic
replacement.
