KRYOTEC ENGINE
101
3. Install the right front wheelhouse splash shield
(Refer
to
23
-
Body/Exterior/SHIELD,
Splash/Removal and Installation).
4. Install the right front tire and wheel assembly
(Refer to 22 - Tires and Wheels/Removal and
Installation).
5. Remove the support and lower the vehicle.
G. OIL COOLER
REMOVAL
1. Remove the engine cover (Refer to 09 -
Engine/COVER, Engine/Removal and Installation).
2. Remove the starter (Refer to 08 -
Electrical/Starting/STARTER/Removal
and
Installation).
3. Drain the engine coolant (Refer to 07 -
Cooling/Standard Procedure).
4. Release the clips and disconnect the coolant
supply and return hoses (1).
5. Disconnect the coolant return hose (1) to the
water pump.
