KRYOTEC ENGINE
108
K. DIESEL HIGH PRESSURE
REMOVAL
1. Disconnect and isolate the negative battery
cable.
2. Remove the engine cover (Refer to 09 -
Engine/COVER, Engine/Removal and Installation).
3. Raise and support the vehicle (Refer to 04 -
Vehicle
Quick
Reference/Hoisting/Standard
Procedure).
4. Remove the starter (Refer to 08 -
Electrical/Starting/
STARTER/Removal
and
Installation).
5. Disconnect the oil pressure sensor wire harness
connector (1).
6. Remove the oil pressure sensor (2).
FITMENT
1. Install the oil pressure sensor (2) and tighten to
the proper (Torque Specifications).
2. Connect the oil pressure sensor wire harness
connector (1).
3. Install the starter (Refer to 08 -
Electrical/Starting/STARTER/Removal
and
Installation).
4. Remove support and lower the vehicle.
5. Install the engine cover (Refer to 09 -
Engine/COVER, Engine/Removal and Installation).
6. Connect the negative battery cable.
