KRYOTEC ENGINE
106
16. Fill the engine with recommended oil (Refer to
04 - Vehicle Quick Reference/Capacities and
Recommended Fluids - Specifications).
17. Install the front fascia (Refer to 13 - Frame and
Bumpers/Bumpers/FASCIA, Front/Removal and
Installation).
18. Install the left front wheelhouse splash shield
(Refer
to
23-
Body/Exterior/SHIELD,
Splash/Removal and Installation).
19. Install the right front wheelhouse splash shield
(Refer
to
23-
Body/Exterior/SHIELD,
Splash/Removal and Installation).
20. Install the belly pan (Refer to 13- Frame and
Bumpers/Under
Body
Protection/BELLY
PAN/Removal and Installation).
21. Remove the support and lower the vehicle.
22. Connect the negative battery cable.
J. DIESEL WARNING LIGHT
REMOVAL
1. Disconnect and isolate the negative battery
cable.
2. Remove the engine cover (Refer to 09 - Engine/
COVER, Engine/Removal and Installation).
3. Remove the nut (1a) and position aside the glow
plug module (1b).
4. Disconnect the Powertrain Control Module
(PCM) wire harness connectors (1a, 1b).
