FATC
12
ii. BLOWER SPEED CONTROL KNOB (Round
knob)
Rotate the knob clockwise to increase the blower
speed up to MAX (Speed 7), whereas anticlock-
wise would reduce the speed up to Min (Speed 1).
iii. ECON Button
During ECON AC operation, the system automatical-
ly cuts off compressor at a higher temperature than
normal AC. The operation can be used during mild
weather conditions for battery saving.
Comfort level may be compromised during this oper-
ation. By pressing ECON button text will be
displayed on display.
iv. MAX DEFROST BUTTON
a. This button directs the main airflow towards
windscreen for faster defrosting (It also over-
rides any mode selection you may have made.)
b. When you turn off the button, the system returns
to its former settings. On pressing this button,
the LED is illuminated indicating air distribution
to max defrost mode is ON.
CAUTIONS:
For your safety make sure you have a clear view
through all the windows before driving.
v. REAR WINDOW DEMISTER BUTTON:
This button turns the rear window demister ON or
OFF. The system will be deactivated after 15 min of
continuous operation.
vi. FRESH AIR / RECIRCULATION BUTTON:
When the recirculation Button or LED is switched
‘ON’, air from the vehicle’s interior is sent throughout
the system.
When the recirculation button is switched ‘OFF’, air
is brought in from outside of the vehicle (fresh
mode). Whenever discomfort is felt, switch to fresh
air mode.
NOTE
The outside air intakes for the climate control sys-
tems are at the base of windscreen. Keep this area
clear from leaves and other debris.
The system should be used with recirculation air
mode for faster heat up and cool down, however
keeping the system in recirculation mode, particularly
with AC OFF, can cause the windows fog up.
vii. AIR DISTRIBUTION (MODE) BUTTON:
In AUTO mode, the FATC system will regulate the
mode automatically. However, user override is pos-
sible with the use of MODE button to select the
desired airflow mode.
Each time you press the MODE button, the display
shows the mode selected.
Directs air through the center and side
air vents
