6F33 TRANSAXLE
31
12. ASSEMBLY OF TRANSAXLE ON VEHICLE:
1. Lift the transaxle assembly using support stand.
2. Support and lower the engine assembly slightly
and align transaxle assembly with engine
assembly.
3. Fit gearbox housing on to engine by aligning the
hole between flex-plate and Torque-Converter
lug hole and pretighten them.
4. Fix the ‘B’ mount bolt and tighten it to specified
torque.
5. Fix ‘C’ mount bracket to transaxle housing and
remove engine support.
6. Start the bolting of flex plate from Slot hole on
Flex plate. And Tight all bolts on Flex plate from
starter motor side. (Refer docking procedure for
further details).
7. Fix the starter motor.
8. Connect earthing cable to Gear Box.
