6F33 TRANSAXLE
34
13. REMOVAL OF GEAR SHIFTING CABLE ON
VEHICLE:
1. Ensure GSL shifter placed in “N” mode (Neutral
mode) before removal the battery.
Warning:
If vehicle is in ignition-off condition, and Gear shift
lever stuck in P mode (Park Mode). Press and hold
the release button provided on shifter housing till
you move the shifter from P (park) mode to N
(Neutral) mode.
2. Remove the battery connection and surrounding
air filter parts.
3. Place/lock the transaxle shift lever in “N” mode
(Neutral mode) by matching/aligning shift lever
hole & Inhibitor switch hole on transaxle with the
help of
Locking pin tool 541258900605.
4. Remove Nut from Gear shifting cable grommet
fitted on chassis firewall.
5. Remove screw & pull out side shield from LH &
RH side.
6. Remove Handle from LH & RH side.
