6F33 TRANSAXLE
29
9. Remove Brake Caliper mounting and hang it on
vehicle using S-hook.
10. Disconnect vehicle speed sensor connection
from transaxle.
11. Remove ball joint (steering rack) from steering
knuckle from both sides.
12. Remove Mountings on lower control arm and
disconnect lower control arm.
13. Swing out both drive shafts from transaxle and
hang it suitably with the help of hook 5123 5890
2403.
CAUTION
Do not pull drive shaft excessively as the
inboard joint (tripot assembly) will come out of
housing and damage the boot. Do not place the
CV drive shaft on rough / uncleaned surfaces.
This might damage the drive shaft boot.
14. Disconnect earthing cable Gear Box.
15. Disconnect the oil lines from transmission side.
16. Support engine suitably using engine lifting
crane.
17. Remove the starter motor.
