6F33 TRANSAXLE
28
11. REMOVAL
OF
TRANSAXLE
FROM
VEHICLE:
1. Park the vehicle and apply the parking brake.
2. Shift the gear lever to neutral position.
3. Lift the vehicle on using two post lift and remove
the front wheels.
4. Remove the engine guard.
5. Drain the Transaxle oil.
6. Disconnect Electrical connection of the AT
harness and inhibitor switch.
7. Disconnect gear shifter and selector cables.
8. Remove Drive shaft Lock Nut.(Note: Apply
Brake while removing Lock nut.
