300 / 745
6F33 TRANSAXLE
32
9. Connect the oil lines at transmission side.
NOTE:
Check the hoses condition (damage / loose) &
replace if required.
Refer hose fitment procedure for further details.
10. Fill transaxle oil through filler plug. (Refer ATF
oil level checking procedure for further details).
11. Connect gearshift cables and follow the neutral
setting procedure for further details.
12. Align and insert both LH and RH sides drive
shaft assemblies into transaxle carefully.
CARE SHOULD BE TAKEN NOT TO DAMAGE
DRIVESHAFT OIL SEAL AND ITS BOOTS (DO
NOT USE HAMMER).
Ensure that splined end of driveshaft is inserted
fully in differential gear.
13. Tighten Drive shaft Lock Nut.
NOTE:
Do not reuse the lock nut.
14. Assemble ball joints on lower link (both RH and
LH).
