1.5L REVOTORQ ENGINE

164

16.Place the catcon gasket on the turbocharger.

Make sure to use new gasket when installing.

17.Install the catcon assembly with the

turbocharger outlet.

18.Install the turbocharger support brackets and

fix the catcon assembly to turbocharger.

19.Install oil cooler assembly

20.Install the oil filter adapter.

21.Install the oil filter using special tool.
