1.5L REVOTORQ ENGINE
166
8. Install the intake manifold assembly. Use
specified torque and tightening sequence.
9. Fit the air intake elbow along with throttle valve
assembly and, air temperature sensor
connected to it. Make sure to use new gasket
when installing.
10.Fit the fasteners of bracket for dipstick tube
mounting.
11.Install the H.P. fuel line connected to the fuel
rail.
12.Install the EGR valve using fasteners. Make
sure to use new gasket when installing.
13.Connect EVRV hose to EGR valve.
