207 / 1119
1.5L REVOTORQ ENGINE
19
Air Filter, Snorkel, Blow By Pipe
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Engine Cover
02
Foam, Engine Cover
03
Hex Fl. Scr. M8x20
2.3
04
Bracket Assy, Air Filter Mtg.
05
Rubber Grommet, Air Filter Mtg.
06
Screw, Air Filter Hsg. Self Tapping Screw
0.3
07
Tap Scr. C-St4.8x13
0.3
08
Bracket For Snorkel Mtg.
09
Grommet, Snorkel Bracket
10
Snorkel Assy. With Mesh
11
H/Fl Bolt M8x35
0.5
12
H/Fl Bolt M8x35
0.5
13
Air Filter Assy
14
Air Mass Flow Sensor
15
Clamp, Worm Drive, 60-80/9
3 – 3.5
16
Hose Assy, HFM To TC
17
Clamp, Worm Drive, 40-60/9
3 – 3.5
18
Hose, Oil Separator To Air Filter Hose
19
Spring Band Clamp
20
Ball head pin
21
Engine cover mounting bracket
22
H/FL Scr M8X16
0.95
