211 / 1119
1.5L REVOTORQ ENGINE
23
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
12
Hollow Dowel (Qty. 2)
13
Water Pump Assy.
14
Gasket (Water Pump)
15
Hex. Flange Bolt M12x69
4.5
16
Idler Pulley
17
Spacer (Timing Belt Idler)
18
Cap Screw M6x20
0.8
19
Hex. Flange Screw M6x16 (Qty. 3)
0.8
20
Pin (Timing Cover Mounting)
21
Timing Cover Assy., (Back)
22
Timing Gear - Camshaft ( Front )
23
Washer For Camshaft Gear
24
Hex. Bolt (Camshaft Gear Mtg.)
11.5 + 0.5
25
Auto Tensioner Assy.
26
Locating Pin
27
Stud C M8x30
28
Hex. Flange Nut Am8
3.0
29
Timing Gear (FIP)
30
Nut (FIP) (For FIP Gear)
