ALTROZ SERVICE MANUAL

213 / 1119

1.5L REVOTORQ ENGINE
25
Exhaust manifold, CATCON, Turbocharger
ITEM
NO.
DESCRIPTION
NO REUSESEALANT
LUBRICATIONTIGHTENING
TORQUE
(kg-m)
01 Turbocharger Assy.
02 Heat Shield Assy.,Turbocharger -
03 Hex. Flange Screw M8x18 (Qty. 2) 1.5
04 Gasket (TC Outlet To Cat. Con.)
05 Close Coupled Catcon Assy.
06 H/FL Screw M8X25 3.0
07 Hex. Flange Screw M8x18 (Qty. 2) 3.0
08 Bracket Assy. (CCC Support)
09 Flanged Clinch Nut (Qty. 10) 2.0 + 0.3
10 Stud C M8x32 (Qty. 10) 2.0 + 0.3
11 Exhaust Manifold
12 Gasket, Exhaust Manifold
13 Hex. Flange Screw M8x18 (Qty. 2) 1.5
14 Heat Shield Assy., Exhaust Manifold, Top
15 Gasket, TC Intake To Exhaust Manifold
16 Stud C M8x32 (Qty. 2) 2.0 + 0.3
17 Flanged Clinch Nut (Qty. 3) 3.0
18 Bracket, Turbocharger (Turbo Support)
19 Hex Flange Screw M8x25 2.0
20 Bracket (Turbo Support)
21 Hex. Flange Bolt M8x18 2.0
22 Flanged Clinch Nut (Qty. 3) 3.0
23 H/FL Bolt M8X95
24 H/FL Bolt M8x25
25 Lambda Sensor
