1.5L REVOTORQ ENGINE
17
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
24
Pipe Union Bolt (For Oil Feeder) (Qty. 2)
2.0
25
Hex Flange Screw M6x18 (Qty. 2)
1.0 + 0.2
26
Gasket (TC Oil Return Line To Block
27
Gasket, Piston Cooling Nozzle (Qty.4)
28
Nozzle Assembly, Piston Cooling Piston
Cooling (Qty.4)
29
Cap Screw M5x10 (Qty.4)
0.8
30
Rubber Cap (For Cooling Hoses)
31
Spring. Band Clamp 27dx12w
32
Hex_Screw_M8x25 (Qty. 2)
2.0
33
Elbow Assembly (Water Intake)
34
Plain_Washer_M6
35
Oil Sump Gasket
36
Oil Sump Gasket
37
Plain_Washer_M8
38
Oil Cooler Assy
39
Turbocharger Assy -
