202 / 1119
1.5L REVOTORQ ENGINE
14
Intake Manifold and Fuel Injection System
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Nut (Fip) (For Fip Gear) M14x1.5
5.0
02
Timing Gear (Fip)
03
Cap Screw M6x16
04
Hex. Bolt (M8x75.5) (Qty. 3)
2.7 + 0.3
05
HP Pump
06
Assy. Fuel Pr. Line (Pump To Rail)
*
2.5 with sleeve or
3.0 without sleeve
07
Hex. Flange Screw M6x12
08
Spring Washer 8
09
Cap Screw M8x35 (Qty. 3)
2.0 + 0.3
10
Cap Screw M8x22 (Qty. 4)
2.0 + 0.3
11
Intake Manifold
12
Flanged Clinch Nut (Qty. 2)
2.0 + 0.3
13
Stud C M8x30 (Qty. 2)
14
Hex. Flange Bolt M8x38 (Qty. 3)
2.0 + 0.3
15
Assy Fuel Rail.
16
Fuel Injector (Qty. 4)
17
Pin (Injector Claw Support) (Qty. 4)
18
Injector claw (Qty. 4)
19
Spherical. Washer (Injector Claw) (Qty. 4)
20
Hex. Flange Bolt M8x45 (Qty. 4)
2.9 + 0.3
21
Assy. Fuel Pr. Line (Rail To Injector) (Qty.
4)
*
2.5 with sleeve or
3.0 without sleeve
22
Gasket (Intake Manifold)
Note:-
•
This Symbol indicates critical tightening torque.
*
Cap connector for fuel pressure line M14x1.5 (H.P. line with sleeve)
*
Cap connector for fuel pressure line M14x1.5 (H.P. line without sleeve)
