1.2L REVOTRON ENGINE
92
18. Disconnect the fuel supply connection to
Engine by relieving the fuel pressure.
19. Remove canister connections from canister
purge valve mounted on intake manifold.
20. Disconnect suction and discharge hoses
connected from the compressor.
21. Remove Translink cable or AMT coupler.
22. Remove Tie Rod
23. Remove exhaust front pipe.
24. Remove front two tyres.
25. Disconnect the left and right drive shafts from
the vehicle. (For procedure refer Transaxle
Draft)
26. Use suitable belt/chain to fix a zip crane to the
engine lifting hooks located at front and rear of
the engine.
27. Raise the crane slightly up until very light
pressure is applied to the engine.
