1.2L REVOTRON ENGINE
91
10. Drain the engine coolant by removing drain
plug into a suitable container.
11. Drain the transaxle oil from the vehicle.
12. Rotate the tensioner point by using ring
spanner opposite to belt tension and remove
the belt.
13. Recover A/C gas, using recovery unit.
14. Disconnect and remove the auxiliary tank and
hoses from engine.
15. Remove the Heater hoses connection to the
engine.
16. Remove all the hoses connected between
radiator and engine.
17. Disconnect and remove vacuum hose
connected between brake booster to vacuum
pump.
